All In One Chemical Cleaning Line Inline Integration For Stainless Steel

Brand Name:	Hongshun
Model Number:	HS-6210STP
MOQ:	1 set
Price:	$20,000 to $50,000
Packaging Details:	film
Payment Terms:	L/C,T/T

Detail Information

Product Description

Detail Information

Place of Origin:

Dongguan

Certification:

CCC/CE

Applications:

Stainless Steel

Pure Water:

Consumption Of 5~15L Per Minute

Water Pressure:

0.3Mpa

Main Power Supply:

380±10%/50HZ

Electronic Control System:

Omron PLC

Inlet Pipe Diameter:

1.25″

Supply Ability:

5 sets/month

Highlight:

All In One Chemical Cleaning Line

Stainless Steel Chemical Cleaning Line

Inline Integration stainless steel passivation equipment

Product Description

All In One Chemical Cleaning Line Inline Integration For Stainless Steel

Revolutionary All-In-One Cleaning & Passivation Line for Stainless Steel

Unleash unparalleled efficiency with our integrated production line, featuring a three-stage ultrasonic cleaning system, automated chemical passivation, and rapid-dry technology. Its modular structure allows for easy expansion, while the PLC-controlled interface ensures precise process customization. Ideal for stainless steel products in food, medical, and kitchenware industries.

Core Keywords: stainless steel cleaning passivation line, all-in-one production line, integrated cleaning system

Process Flow of All-In-One Cleaning & Passivation Line

Manual feeding
Ultrasonic degreasing No.1
Ultrasonic degreasing No.2
Ultrasonic washing No.3
Passivation No.4
Ultrasonic pure water washing No.5
Pure water washing No.6
Manual water blow-off
Tunnel furnace drying
Convey to full inspection platform

Technical Specifications: Ultrasonic Cleaning Tanks No.1 and No.2

Parameter	Specification
Quantity	Two tanks
Cleaning Tank Structure	Inner tank size: L815×W820×H1550mm (effective use size)
Material Quality	SUS304, 2mm thick stainless steel plate with reinforcement for strength
Configuration	Liquid inlet, bottom discharge port, insulation cotton, electric heating with Omron digital temperature control (RT-100°C)
Ultrasonic System - Vibration Plate	Chromium-plated working surface, bottom vibration method, 1 plate per tank with 60 vibration units, 3000W power per plate, 28KHZ frequency, continuously adjustable output power
Ultrasonic Generator	Excitation method with scanning circuit, continuously adjustable output power, automatic workpiece detection for energy efficiency
Filter System	Circulating filtration system with pump, valve, pipeline and reservoir
Cleaning Solvent	Water soluble cleaning agent + municipal water

For a complete technical solution of All-In-One Cleaning & Passivation Line, please contact us.

We will customize the design based on your product technical requirements and factory layout.

Our Typical Customers

About Us

Dongguan Hongshun Automation Equipment Co., Ltd. is located in Dongguan City, the global manufacturing capital. We are a professional manufacturer of high-precision surface treatment equipment specializing in:

Ultrasonic cleaning equipment
Vacuum hydrocarbon cleaning machines
High-pressure spray cleaning machines
Spraying lines
Passivation acid washing equipment
Anodizing equipment
Electroplating equipment
Industrial pure water machines
Reclaimed water reuse equipment
Tunnel drying furnaces and peripheral equipment

We provide turnkey surface treatment projects for our customers. The company integrates independent research and development, production and manufacturing, installation and training, and after-sales service. We maintain a complete quality management system and strong technical strength.
