Manual Transfer 8 Tank Ultrasonic Cleaning Machine With Oscillation Mechanism

1 set
MOQ
$4,000 to $8,000
Price
Manual Transfer 8 Tank Ultrasonic Cleaning Machine With Oscillation Mechanism
Features Gallery Product Description Chat Now
Features
Specifications
Applications: Metal Parts
Total Ultrasonic Power: 7.5 KW
Equipment Capacity: 3-5 Minutes / Basket
Power Supply: 380±10%/50HZ
Heating Temperature: 80℃
Ultrasonic Frequency: 28 KHZ
Highlight:

8 Tank ultrasonic cleaning machine

,

Manual Transfer ultrasonic cleaning machine

,

Oscillation Mechanism ultrasonic cleaning system
Basic Infomation
Place of Origin: Guangdong
Brand Name: Hongshun
Certification: CCC/CE
Model Number: HS-8050SW
Payment & Shipping Terms
Packaging Details: film
Delivery Time: 20 days
Payment Terms: L/C,T/T
Supply Ability: 5 sets/month
Product Description

Manual Transfer 8 Tanks Ultrasonic Cleaning Machine With Oscillation Mechanism



Ultrasonic Cleaning Machine Overview:

This manual transfer 8-tank ultrasonic cleaning machine features an oscillation mechanism to enhance cleaning efficiency. The 8-tank system (pre-soak, ultrasonic wash, 3-stage rinse, passivation, drying) caters to complex cleaning needs. With adjustable frequencies (28-40kHz), it adapts to various metal parts.



The oscillation mechanism agitates parts, dislodging stubborn contaminants like oil, wax, and debris. Each tank has temperature control (30-80℃), optimizing detergent performance. Manual transfer allows careful handling of delicate components.



Ideal for precision parts in aerospace, automotive, and electronics industries—such as gears, connectors, and small hardware. The final drying tank with hot air ensures <0.1% moisture, preparing parts for assembly or coating. Boosts productivity by 40% vs single-tank cleaners.



Process configuration table of 8 Tanks Ultrasonic Cleaning Machine :

 order

 process flow

Ultrasonic power

 service substance

 wash

 time

 working temperature

1

 loading









2

Ultrasonic cleaning with wash agent

1.5KW

28KHZ

Cleaner + municipal water

2-5min

50-60 degrees

3

Ultrasonic cleaning with wash agent

1.5KW

28KHZ

Cleaner + municipal water

2-5min

50-60 degrees

4

Ultrasonic cleaning with wash agent

1.5KW

28KHZ

Cleaner + municipal water

2-5min

50-60 degrees

5

Ultrasonic cleaning with wash agent

1.5KW

28KHZ

Cleaner + municipal water

3-5min

50-60 degrees

6

City water rinsing



City water

2-3 min

RT

7

City water rinsing



City water

2-3 min

RT

8

City water rinsing



City water

2-3 min

RT

9

The ultrasonic water rinsing

1.5KW

28KHZ

City water

2-5min

50-60 degrees





Main technical parameters of the Ultrasonic Cleaning Line:

Total ultrasonic power

 7.5KW (a total of 5 ultrasonic tanks, each 1.5KW)

Ultrasonic frequency

 28KHz.

Maximum total power of the equipment

 20 KW.

Power supply

 380VAC, 3p5w,50HZ.

Machine size

 (length x width x height) approximately according to the drawing or physical object



 For a complete technical solution Of  Ultrasonic Cleaning Line, please contact me. We will customize the design based on your product technical requirements and factory layout.
