Solar Photovoltaic Flat Glass Washing Machine Spray Roller Brush Compact Glass Washer

Brand Name:	Hongshun
Model Number:	HS-2500MAF
MOQ:	1 set
Price:	$20,000 to $40,000
Packaging Details:	film
Payment Terms:	L/C,T/T

Detail Information

Product Description

Detail Information

Place of Origin:

Guangdong

Certification:

CCC/CE

Applications:

Solar Photovoltaic Glass Panel

Processing Capacity:

250-400 Panels/hour

Max Glass Size:

2100×1650mm

Power Supply:

380±10%/50HZ

PLC:

Mitsubishi Of Japan

Touch Screen:

Taiwan's "HITECH"

Pneumatic Controller:

Japan “SMC”

Supply Ability:

5 sets / month

Highlight:

Solar Photovoltaic Flat Glass Washing Machine

Roller Brush Flat Glass Washing Machine

Solar Photovoltaic Compact Glass Washer

Product Description

Solar Photovoltaic Flat Glass Washing Machine

Professional Spray Roller Brush Compact Glass Washer

This specialized solar photovoltaic glass panel spray roller brush cleaning machine is engineered specifically for PV glass applications, ensuring optimal light transmittance that is critical for maximum energy efficiency in solar panels.

Key Features & Performance

Soft, anti-static roller brushes with adjustable pressure (0.2-0.4MPa) gently remove dust, silicone residues, and oxide films
Preserves panel's light-absorbing capacity without scratching textured glass surfaces
High-pressure deionized water spray system (6-10bar) effectively flushes contaminants
Dual-stage air knife system (0.6-0.9MPa) eliminates 99.9% moisture to prevent water spots
Designed for 3.2mm/4mm PV glass processing at 250-400 panels per hour
Handles panel sizes up to 2100×1650mm
Seamless integration into existing solar module production lines
PLC-controlled for precision cleaning operations

Performance Note: A leading PV manufacturer reported "Light transmittance improved by 2.3% post-cleaning," demonstrating the machine's effectiveness in maximizing solar panel performance and longevity.

Technical Specifications & Materials

Order Number	Main Unit	Brand/Material	Explanation
1	Conveying shaft spacing	100㎜	Rolling brush section 110㎜
2	Rack material	SUS304 50x50x2㎜ square tube
3	Main cleaning tank	"South Asia" transparent PVC board	T=10mm
4	Water box	Taiwan "South Asia" transparent/ivory PVC board	T=10mm
5	Door plank	Taiwanese "South Asia" ivory PVC board	T=6mm
6	Upper cover plate 1	Taiwan "South Asia" transparent PVC board	T=6mm T=1.5mm
7	Anti-leak liquid collection tray	Taiwanese "South Asia" ivory PVC board	T=8mm
8	Feeding roller 1	SUS304 shaft core
9	Pressing roller 2	SUS304 shaft core coated with rubber	Φ 32mm (brush section)
10	Feeding roller surface	White UPE roller + white fluorine rubber O ring	Two ends supported by guide wheel, middle is freewheel of fluororubber
11	Final drive shaft	Imported bearing steel	φ20mm
12	Pipe system	"Anchor plate" PVC Sprinkler pipe: 3/4"PVC	Total inlet pipe: 1" PVC Total drain pipe: 2"PVC
13	Touch screen	Taiwan's "HITECH"	10.4 inches
14	PLC	Mitsubishi of Japan
15	Contactor/circuit breaker	"Spanx"
16	Frequency transformer	Japan's Panasonic
17	Thermostat	Japan "OMRON"
18	Inductor	Japan "OMRON"
19	Pneumatic controller	Japan "SMC"
20	Water pump	South China
21	High pressure positive blower	China's "Sen Sen"
22	Drive motor	Taiwan "Tai Li"
23	Roll brush motor	Taiwan "Tai Li"

Custom Technical Solutions

For a complete technical solution for Solar Photovoltaic Glass Panel Spray Roller Brush Cleaning Machine, please contact us. We will customize the design based on your specific product technical requirements and factory layout.
