High-Speed Aluminum Profile Vertical Powder Coating Line Boost Productivity

1 set
MOQ
$350,000 to $550,000
Price
High-Speed Aluminum Profile Vertical Powder Coating Line Boost Productivity
Features Gallery Product Description Chat Now
Features
Specifications
Applications: Aluminum Profiles
Maximum Workpiece Size: 200mm × 200mm × H6000mm
Standard Speed Of Conveyor Chain: 3500mm/min (1000mm/min--5000mm/min Variable Frequency Adjustable)
Power Supply: 380±10%/50HZ
Weight Of Standard Workpiece: 3KG
Elevator Drive System: German SEW
Elevator Frequency Converter Controller: Mitsubishi
Basic Infomation
Place of Origin: Guangdong
Brand Name: Hongshun
Certification: CCC/CE
Model Number: HS-3900VPQ
Document: Technical documents for ver...ne.pdf
Payment & Shipping Terms
Packaging Details: film
Delivery Time: 65 days
Payment Terms: L/C,T/T
Supply Ability: 5 sets/month
Product Description

High-Speed Aluminum Profile Vertical Powder Coating Line - Boost Productivity in Southeast Asia


Vertical Powder Coating Production Line Overview:

Our High-Speed Aluminum Profile Vertical Powder Coating Line is tailored to supercharge productivity for Southeast Asia (SEA) manufacturers, delivering fast, consistent finishes for aluminum profiles (doors, windows, furniture frames) to meet the region’s booming construction and furniture demand.

Engineered for speed, it cuts total coating cycles by 30% vs. standard lines: its optimized pre-treatment stations use high-pressure rinsing to shorten cleaning time, while the advanced electrostatic spray system (with dual-nozzle design) and rapid-curing oven (180-220℃ with heat recirculation) accelerate processing—achieving a throughput of up to 600kg/h. The vertical layout saves 40% floor space (ideal for compact SEA workshops) and integrates fully automated loading/unloading to eliminate manual delays.

Built to withstand SEA’s high humidity with corrosion-resistant components, it requires minimal downtime for maintenance. For SEA manufacturers aiming to scale output without sacrificing quality (compliant with local industry standards), this high-speed line is a game-changer—turning higher productivity into greater market competitiveness.

Design principles and characteristics:

1, The new type of fast color changing spray booth with “+” shape is made of sandwich material, which has good insulation performance and can improve the rate of powder application.

2, The single-layer cloth gun with “+” shape spray booth reduces the orange peel caused by reverse electroionization of static electricity in multi-layer cloth guns, and the single-layer cloth gun also has a higher powder rate than multi-layer cloth guns.

3, The “+” shaped spray booth uses a one-character cloth gun, and the spray gun and chain remain perpendicular to each other to ensure that the nozzle is directly facing the aluminum profile groove to improve powder on the groove.

... ...



Energy consumption reference of Vertical Powder Coating Production Line:



SN.

 device name

Maximum installed capacity

Maximum gas supply

( natural gas )

1.

 conveyer system

6KW/H



2.

 pretreatment

61KW/H



3.

Drying oven (proportion combustion machine) 1 set

15KW/H

30M³/H

4.

Spraying system (1 set)

75W/H



5.

Curing furnace (proportion combustion machine) 1

15KW/H

90M³/H

6.

Elevator, upper and lower material conveying mechanism

12KW/H



7.

Floc incineration unit (2 burners)

23KW/H

25M³/H

8.

 amount

207KW/H

145M³/H



 For a complete technical solution Of  Vertical Powder Coating Production Line Equipment For Aluminum Profiles, please contact me. We will customize the design based on your product technical requirements and factory layout.


Our typical customers:

   High-Speed Aluminum Profile Vertical Powder Coating Line Boost Productivity 0

  High-Speed Aluminum Profile Vertical Powder Coating Line Boost Productivity 1




About Us:

Dongguan Hongshun Automation Equipment Co., Ltd. is located in Dongguan City, the global manufacturing capital. It is a professional manufacturer of high-precision surface treatment equipment. Its main products include: We offer a full range of ultrasonic cleaning equipment, vacuum hydrocarbon cleaning machines, high-pressure spray cleaning machines, spraying lines, passivation acid washing equipment, anodizing equipment, electroplating equipment, industrial pure water machines, reclaimed water reuse equipment, tunnel drying furnaces and their peripheral supporting equipment and consumables, etc. We provide turnkey surface treatment projects for our customers. The company integrates independent research and development, production and manufacturing, installation and training, and after-sales service. It also has a complete quality management system and strong technical strength.
