Home /Products/Automated Anodizing Line/Semi-Automatic Anodizing Line With 2 Gantry Cranes For Aluminum Part Flexibility

Semi-Automatic Anodizing Line With 2 Gantry Cranes For Aluminum Part Flexibility

1 set
MOQ
$100,000 to $200,000
Price
Semi-Automatic Anodizing Line With 2 Gantry Cranes For Aluminum Part Flexibility
Features Gallery Product Description Chat Now
Features
Specifications
Applications: For Aluminum Part
Lifting Capacity: 200-250kg
Water Pressure: 0.3Mpa
Main Power Supply: 380±10%/50HZ
Environmental Temperature: 0℃~45℃ Is Most Suitable
Chillers: 20HP
Highlight:

semi-automatic anodizing line with gantry cranes

,

automated anodizing line for aluminum parts

,

anodizing line with dual crane flexibility
Basic Infomation
Place of Origin: Dongguan
Brand Name: Hongshun
Certification: CCC/CE
Model Number: HS-2000YH
Payment & Shipping Terms
Packaging Details: film
Delivery Time: 75 days
Payment Terms: L/C,T/T
Supply Ability: 5 sets/month
Product Description
Semi-Automatic Anodizing Line With 2 Gantry Cranes For Aluminum Part Flexibility
Product Overview
The HS-2000YH Semi-Automatic Anodizing Line by Dongguan Hongshun Automation combines automation with manual control for flexible aluminum surface treatment. Featuring 2 gantry cranes (SUS304 material, 200-250kg capacity) with semi-automatic control, this system allows manual adjustment for complex workpieces while automating repetitive tasks.
Key Features
  • 4 anodizing tanks (15mm PP material) with 2500A/15V rectifiers for stable current output
  • 20HP water-cooled chillers for precise temperature control (±2℃)
  • Supports 20+ step process including degreasing, neutralization, anodizing, coloring, and sealing
  • Manual intervention available at key stations for small-batch or custom production
  • Omron PLC and Taiwan "Weilun" HMI for process monitoring (time, temperature)
  • Corrosion-resistant construction (PP tanks, SUS304 cranes)
  • Air agitation system (5HP roots blower) for solution uniformity
  • Classified wastewater system meeting global environmental standards
Equipment Working Conditions
Parameter Specification
Environmental temperature 0℃~45℃ (optimal)
Relative humidity ≤90%
Water pressure 0.3Mpa
Steam source 0.2~0.5Mpa
Main power supply 380±10%/50HZ, 25V-3000A rectifier, Refrigerator 22.5KW, Filter 8KW
Process Flow
Semi-Automatic Anodizing Line With 2 Gantry Cranes For Aluminum Part Flexibility 0
For a complete technical solution, please contact us. We customize designs based on your product requirements and factory layout.
After-sales Technical Services
  • 12 months free technical support (excluding consumables)
  • Lifetime paid technical support after warranty
  • Chinese and English documentation provided
  • Mechanical and electronic parts provided for one year
  • Warranty copy with effective date and coverage
  • On-site monitoring by engineers within 6 months after delivery
Application Fields
Semi-Automatic Anodizing Line With 2 Gantry Cranes For Aluminum Part Flexibility 1
Semi-Automatic Anodizing Line With 2 Gantry Cranes For Aluminum Part Flexibility 2
Semi-Automatic Anodizing Line With 2 Gantry Cranes For Aluminum Part Flexibility 3
Contact us for more information about our Semi-Automatic Anodizing Line solutions.
