Zinc Plated Parts Spray Cleaning Machine Hardware Manufacturing Ultrasonic Cleaning Line

Brand Name:	Hongshun
Model Number:	HS-2300SC
MOQ:	1 set
Price:	$100,00 to $30,000
Packaging Details:	film
Payment Terms:	L/C,T/T

Detail Information

Product Description

Detail Information

Place of Origin:

Guangdong

Certification:

CCC/CE

Applications:

Zinc Plated Parts

Conveyor Speed:

3-10m/min

Spray Pressur:

90bar

Power Supply:

380±10%/50HZ

Dryer Temperature:

Ultrasonic Frequency:

28KHZ

Supply Ability:

5 sets/month

Highlight:

Zinc Plated Parts Spray Cleaning Machine

Hardware Manufacturing Spray Cleaning Machine

Hardware Manufacturing Ultrasonic Cleaning Line

Product Description

Zinc Plated Parts Spray Cleaning Machine for Hardware Manufacturing

Spray washer specifically designed for zinc plated parts with low pressure setting drying system, ideal for hardware manufacturing applications.

Spray Washer Overview

Low pressure (90bar) setting protects zinc plating on hardware parts. The comprehensive spray system ensures complete surface coverage, while the 50℃ dryer prevents plating damage. Specifically designed for hardware manufacturing of door handles and hooks, effectively removing polishing wax and fingerprints.

Cleaning Requirements Reference

Total residue weight ≤ 4.5mg
Metal particle diameter ≤ 600μm
Non-metallic particle diameter ≤ 1800μm
Fiber length ≤ 4000μm
No surface watermarks after cleaning (with pure water machine)
Complete drying including blind holes

Process Flow Reference

Manual feeding → Ultrasonic cleaning → Fixed-point spraying → Air cutting → Fixed-point spraying → Mobile spraying → Mobile air cutting → Fixed-point air cutting → Vacuum drying → Cooling section → Automatic unloading (truss manipulator) → Full inspection and packaging

Partial Configuration - Mobile Spraying Rinsing (Pure Water)

Mobile Mechanism	Electric cylinder + servo drive system with capability for external spray pipe or compressed air nozzle addition
Structure	Electric cylinder (1 set), Two SUS hardened guide rods, Import sliders (4 sets)
Important Note	If cleanliness standards cannot be achieved, water at this station cannot be reused

Mobile Mechanism Schematic

Complete Technical Solution

For a complete technical solution of the spray washer, please contact us. We provide customized designs based on your specific product technical requirements and factory layout.

Our Typical Customers

About Our Company

Dongguan Hongshun Automation Equipment Co., Ltd. is located in Dongguan City, the global manufacturing capital. We are professional manufacturers of high-precision surface treatment equipment. Our comprehensive product range includes ultrasonic cleaning equipment, vacuum hydrocarbon cleaning machines, high-pressure spray cleaning machines, spraying lines, passivation acid washing equipment, anodizing equipment, electroplating equipment, industrial pure water machines, reclaimed water reuse equipment, tunnel drying furnaces and peripheral supporting equipment and consumables. We provide complete turnkey surface treatment project solutions, integrating independent research and development, production manufacturing, installation training, and after-sales service with a comprehensive quality management system and strong technical capabilities.
