Customize Large-scale Spray Washing Machine Automatic Rinsing Of 5 Tons Of Heavy Machinery Parts

Brand Name:	Hongshun
Model Number:	HS-Q5000AF
MOQ:	1 set
Price:	$200,000 to $300,000
Packaging Details:	film
Payment Terms:	L/C,T/T

Detail Information

Product Description

Detail Information

Place of Origin:

Dongguan

Certification:

CCC/CE

Applications:

Heavy Machinery Parts

Maximum Weight Of Cleaning Workpiece:

6000Kg

Handling Mode:

Chain Conveyor

Power Supply:

380±10%/50HZ

Handling Speed:

0--12m/min

Natural Gas:

8500Kcal/m3

Supply Ability:

1 sets/month

Highlight:

large-scale spray washing machine

automatic rinsing spray cleaner

5-ton heavy machinery parts washer

Product Description

Customize Large-scale Spray Washing Machine Automatic Rinsing Of 5 Tons Of Heavy Machinery Parts

Spray Cleaning Machine Overview

Our Customize Large-scale Spray Washing Machine is engineered for automatic rinsing of 5-ton heavy machinery parts including mining equipment housings, excavator engine blocks, and industrial gearboxes. This powerful system combines efficiency with cost-saving natural gas heating technology.

Engineered with a reinforced chamber to accommodate bulky 5-ton components, it features high-pressure automatic spray systems (1.0-1.5MPa) with 360° rotatable nozzles, ensuring thorough rinsing of grease, machining chips, and rust from even hidden cavities. The natural gas heating system rapidly heats rinsing water to 40-80℃ (adjustable), boosting cleaning efficacy while cutting energy costs by 30% compared to electric heating.

The fully automated workflow—from part loading to rinsing and draining—minimizes labor requirements and ensures consistent results. Ideal for heavy equipment, mining, and construction machinery sectors, this customized solution safeguards part integrity, accelerates production cycles, and aligns with cost-saving objectives.

Process Configuration

Order Number	Cleaning Medium	Wash Method	Liquid Temperature (℃)	Ultrasonic	Jittering Way	Recurrence Filter	Calorifier	Purge Tank
1	Alkaline Degreaser	Spray Cleaning	40-50	----	----	50 μ	----	Natural Gas Heating
2	Municipal Water	Spray Cleaning	75-80	----	----	50 μ	----	Natural Gas Heating
3	Compressed Air	Wind Knife + Air Gun Cut Water	RT	----	----	50 μ	----	----

Main Technical Parameters

Basic Parameters

Equipment size (L×W×H): Approximately 14000×5000×3500mm
Handling mode: Through, chain conveyor
Handling speed: 0-12m/min (variable frequency speed regulation)
Handling direction: Feed from the left and discharge from the right
Cleaning objects: Chassis, primary and secondary driving gears, flywheel housing, transfer case, outer shell, gear ring hub, gear ring, sprocket hub, drive disc, connecting disc, central drive shaft, track bolts, tooth block bolts, left and right bearing seats, half shaft support
Maximum size of cleaning workpiece: L4000×W3000×H950mm
Maximum weight of cleaning workpiece: 6000Kg
Production program and production beat: To be communicated

Power Requirements

Power supply: AC380V±5%, three-phase five-wire, 50HZ, approximately 60KW (maximum power consumption)
Water source: 2000L/H, consumption of 20-30L per minute
If pure water is used, the output resistivity of pure water shall be no less than 15MΩ cm
Air source: 0.3-0.8MPa, purification grade 3,3,1, intake manifold 1"
Natural gas: High calorific value: 8500Kcal/m³
Water supply and drainage: Inlet main pipe diameter 1.5", inlet branch pipe diameter 1"
Main drain pipe diameter 3", branch drain pipe diameter 2"
Total exhaust gas suction: 100-150M³/Min

For a complete technical solution of Large-scale Spray Washing Machine, please contact us. We will customize the design based on your product technical requirements and factory layout.

Our Typical Customers

About Us

Dongguan Hongshun Automation Equipment Co., Ltd. is located in Dongguan City, the global manufacturing capital. We are a professional manufacturer of high-precision surface treatment equipment. Our main products include: ultrasonic cleaning equipment, vacuum hydrocarbon cleaning machines, high-pressure spray cleaning machines, spraying lines, passivation acid washing equipment, anodizing equipment, electroplating equipment, industrial pure water machines, reclaimed water reuse equipment, tunnel drying furnaces and their peripheral supporting equipment and consumables. We provide turnkey surface treatment projects for our customers. The company integrates independent research and development, production and manufacturing, installation and training, and after-sales service. We maintain a complete quality management system and strong technical strength.
